HDD 2500 Mud Pump
Product Details:
- Usage Industrial
- Size Different available
- Material Stainless Steel
- Suction Type Normal
- Seals Type Sealed
- Click to View more
X
HDD 2500 Mud Pump Price And Quantity
- 1 Unit
HDD 2500 Mud Pump Product Specifications
- Different available
- Industrial
- Sealed
- Normal
- Stainless Steel
HDD 2500 Mud Pump Trade Information
- 200 Unit Per Month
- 7-10 Days
- All India
Product Description
Introducing the HDD 2500 Mud Pump, a high-quality industrial pump suitable for various applications. This pump is available in different sizes to meet your specific requirements. It features a suction type of normal, making it easy to use and operate. The pumps body is made of sturdy stainless steel material, ensuring durability and longevity. Additionally, the seals are tightly sealed to prevent any leaks, making it a reliable option for your industrial needs. The HDD 2500 Mud Pump is perfect for industries that require a high volume of fluid transfer, including mining, oil and gas, and construction.
Other attributes
- Applicable Industries:Manufacturing Plant, Construction works , Energy & Mining, Other
- Showroom Location: Egypt, India, Kazakhstan, Kyrgyzstan
- Video outgoing-inspection : Provided
- Machinery Test Report : Provided
- Marketing Type: New Product 2024
- Warranty of core components: 1 Year
- Core Components : Gearbox, Pressure vessel, Pump, Gear, Engine, Motor, PLC
- Brand Name : OILLEADER
- Condition :New
- Warranty :1 Year
- Type : Horizontal Directional Drilling Pump
- Model Number :3TP1500
- Type : Triplex Piston Pump
- Lubrication Method : Forced Lubrication
- Max Displacement: 2500L/Min
- Max. Pressure :10 Mpa
- Stroke Length : 177.8mm
- Installed Liner Size: 220mm
- Input Power :300kw
- Outlet Pipe Dia. : 89mm
- Inlet Pipe Dia.: 273mm
- Weight :7500kg
Lead time
| Quantity (sets) | 1 - 1 | > 1 |
| Lead time (days) | 30 | To be negotiated |
Specification
| Pump Model | 3TP-1800 | 3TP-2800 |
| Type | Triplex Piston Pump | Triplex Piston Pump |
| Lubrication Method | Forced Lubrication | Forced Lubrication |
| SPM | 140 | 140 |
| Max Displacement | 1800 L/min475GPM | 2800 L/min (740GPM |
| Max. Pressure | 9 Mpa/1300PSI | 9 Mpa/1300PSI |
| Stroke Length | 152.4mm/6inch | 177.8mm/7inch |
| Installed Liner Size | 190mm (7 1/2inch) | 220 (8 1/2inch) |
| Input Power | 140kw (187HP) | 300kw (400HP) |
| Outlet Pipe Dia. | 89 (3 1/2inch) | 89 (3 1/2inch) |
| Inlet Pipe Dia. | 219 (8 1/2inch) | 273 (10 5/8inch) |
| Weight | 4800kg (10582lbs) | 7800kg (17196lbs) |
| Dimension mm (LxWxH) | 2674x2000x2042mm (802x600x612ft) | 2300x1729x1700mm (690x519x510ft) |
| Performance Sheet | ||||
| SPM | Displacement (L/min) | Pressure Mpa | Displacement (L/min) | Pressure Mpa |
| 60SPM | 780 | 9 | 1220 | 9 |
| 80SPM | 1040 | 7 | 1620 | 7.5 |
| 100SPM | 1300 | 6 | 2030 | 6 |
| 120SPM | 1550 | 5 | 2430 | 5 |
| 140SPM | 1800 | 4 | 2840 | 4.5 |
FAQs of HDD 2500 Mud Pump:
Q: What is the HDD 2500 Mud Pump used for?
A: The HDD 2500 Mud Pump is an industrial-grade pump used for high volume fluid transfer in industries such as mining, oil and gas, and construction.Q: What is the suction type of the pump?
A: The HDD 2500 Mud Pump has a normal suction type, making it easy to use and operate.Q: What material is the pump made of?
A: The pumps body is made of stainless steel, ensuring durability and longevity.Q: Are the seals of the pump tightly sealed?
A: Yes, the seals of the HDD 2500 Mud Pump are tightly sealed to prevent any leaks.Q: What types of businesses can benefit from the HDD 2500 Mud Pump?
A: The HDD 2500 Mud Pump is suitable for a variety of industries, including mining, oil and gas, and construction. It is an ideal option for businesses that require a reliable, high-volume fluid transfer pump.Tell us about your requirement
